• Bi-metal hole saws

Bi-metal hole saws

HSS bi-metal hole saw, 14 mm (625160000)
Bi-metal hole saws
  • Hole saws made of bi-metal with hardened cobalt teeth. Quicker chip removal through a new kind of teeth with irregular tooth shape and division; giving much quicker cuts with less vibration. The larger teeth gaps and the inclination ensure effective chip removal.
  • Quicker and softer chip removal through new kind of teeth with irregular tooth shape and division; thus less vibration
  • For use in cast steel and grey cast iron, stainless steel, constructional steel, aluminium, bronze, copper, PVC, acrylic glass, wood.
  • Maximum cutting depth approx. 35 mm
  • Thread for hole saws-Ø 14-30 mm: 1/2"-20 UNF; thread for hole saws-Ø 32-152mm: 5/8"-18 UNF
  • Use hole saws only with the corresponding arbor and pilot drill.
Diameter Order no.
14 mm 625160000
16 mm 625161000
17 mm 625162000
19 mm 625163000
20 mm 625164000
21 mm 625165000
22 mm 625166000
24 mm 625167000
25 mm 625168000
27 mm 625169000
29 mm 625170000
30 mm 625171000
32 mm 625172000
33 mm 625173000
35 mm 625174000
37 mm 625175000
38 mm 625176000
40 mm 625177000
41 mm 625178000
43 mm 625179000
44 mm 625180000
46 mm 625181000
48 mm 625182000
51 mm 625184000
52 mm 625185000
54 mm 625186000
56 mm 625187000
57 mm 625188000
59 mm 625189000
60 mm 625190000
64 mm 625191000
65 mm 625192000
67 mm 625193000
68 mm 625194000
70 mm 625195000
73 mm 625196000
76 mm 625197000
79 mm 625198000
83 mm 625199000
86 mm 625200000
89 mm 625201000
92 mm 625202000
95 mm 625203000
98 mm 625204000
102 mm 625205000
105 mm 625206000
108 mm 625207000
111 mm 625208000
114 mm 625209000
121 mm 625210000
127 mm 625211000
140 mm 625213000
152 mm 625214000
Extension 300mm for AF 9 adapter (625030000)
Adapter for bi-metal hole saws
  • The hole saw extension provides the connection between adapter and power tool.
Designation Hole saw Ø Shaft type Order no.
Extension - SW9 625030000
Adapter SW 9/ 1/2"-20 UNF 14 - 30 mm SW9 625215000
Adapter SW 9/ 5/8"-18 UNF 32 - 152 mm SW9 625216000
SDS-plus adapter/ 1/2"-20 UNF 14 - 30 mm SDS-plus 625217000
Bi-metal hole saws, assortments
Order no.
Bi-metal hole saw set 1, 8 pcs (625159000)
  • Consisting of:
  • Bi-metal hole saws Ø 19, 25, 38, 44, 68 and 83 mm
  • Arbor for hole saw Ø 14-30 mm (SW 9/ 1/2"-20 UNF)
  • Arbor for hole saw Ø 32-152 mm (SW 9/ 5/8"-18 UNF)
  • Pilot Drill
  • Plastic carry case

 625159000

Bi-metal hole saw set 2, 8 pcs (625434000)
  • Consisting of:
  • Bi-metal hole saw Ø 22,29, 35, 44, 51 and 68 mm
  • Arbor for hole saw Ø 14-30 mm (SW 9/ 1/2"-20 UNF)
  • Arbor for hole saw Ø 32-152 mm (SW 9/ 5/8"-18 UNF)
  • Pilot Drill
  • Plastic carry case

 625434000

Bi-metal hole saw set 3, 11 pcs (625435000)
  • Consisting of:
  • Bi-metal hole saw Ø 19, 22, 29, 35, 44, 51, 57, 64 and 68 mm
  • Arbor for hole saw Ø 14-30 mm (SW 9/ 1/2"-20 UNF)
  • Arbor for hole saw Ø 32-152 mm (SW 9/ 5/8"-18 UNF)
  • Pilot Drill
  • Plastic carry case

 625435000

Pilot drill
Order no.
HSS-G pilot drill 6.35 mm (625220000)
  • For use with the HSS bi-metal hole saws in combination with one of the anchor-head holders: 625215000 to 625218000

Diameter: 6.35 mm
625220000
